| Name: | Motorized Lab Jack: J06DS25 |
|---|---|
Product Description
Motorized Lab Jack, Travel 25mm
Features:
*Regular stages set with stepper motors and RS232 interfaces, can connect with motion controller conveniently.
*High accuracy cross-roller guide for high performance and smooth moving
*Mounting holes both on the top and bottom of table for combine with other stages easily
*The lab jack can be redesigned.
Model Number | J06DS25 |
Travel | 25mm |
Dimension | 200mmx200mm |
Driver | Ball Screw |
Guide | Sliding Guide |
Stepper Motor（1.8°） | 57 |
Material | Aluminum |
Surface Treatment | Black-Anodized |
Loading | 40kg |
Weight | 8.2kg |
Max Speed | 18mm/sec |
Repeatability | 7μm |
Max Static Torque | 80Ncm |
